Pancake Load Cell -450kg

25000 INR/Piece

Get a Price/Quote

Product Details:

Size Approx. 110 mm Diameter x 25 mm Height
Application Material testing, Process control, Industrial weighing
Function Force Measurement
Display Type Analog output (no direct display)
Usage Industrial Weighing, Testing Machines
Connectivity Type Cable connection
IP Rating IP65
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Pancake Load Cell -450kg Price And Quantity

Price 25000 INR/Piece
Minimum Order Quantity 1 Piece

Operating Temperature Range -10°C to +70°C
Excitation Voltage 5-12 VDC
Ultimate Overload 200% of Rated Capacity
Protection Class Hermetically sealed
Safe Overload 150% of Rated Capacity
Output Signal 2 mV/V
Cable Length 3 m standard
Mounting Type Through Hole / Center Hole

Pancake Load Cell -450kg Product Specifications

Automatic Grade Manual
Interface Wired
Power Source External power supply
Material Steel
Application Material testing, Process control, Industrial weighing
IP Rating IP65
Size Approx. 110 mm Diameter x 25 mm Height
Capacity Range 450 Kilograms (kg)
Product Type Pancake Load Cell
Connectivity Type Cable connection
Accuracy 0.05% of Rated Output
Usage Industrial Weighing, Testing Machines
Power Supply 10 VDC (Typical)
Warranty NO RETURN / REPLACEMENT / GURRENTY OR WARRENTY
Color ANY
Features High Accuracy, Low Profile, Robust Construction
Load Compression / Tension
Weighing Scale Type Other
Display Type Analog output (no direct display)
Function Force Measurement

Operating Temperature Range -10°C to +70°C
Excitation Voltage 5-12 VDC
Ultimate Overload 200% of Rated Capacity
Protection Class Hermetically sealed
Safe Overload 150% of Rated Capacity
Output Signal 2 mV/V
Cable Length 3 m standard
Mounting Type Through Hole / Center Hole

Pancake Load Cell -450kg Trade Information

FOB Port EX WORKS AHMEDABAD
Payment Terms Cash Advance (CA), Cash in Advance (CID), Cheque
Supply Ability 100 Piece Per Week
Delivery Time 1 Week
Packaging Details Shipping Cost Will Depend on Location & Volume of Parcel Carton Box
Main Export Market(s) Asia
Main Domestic Market All India

Product Description

Step into the world of precision with our Famed Pancake Load Cell - 450kg. This ace device offers soaring accuracy at 0.05% of the rated output, equipped with a robust steel body and hermetically sealed protection (IP65). Designed for both compression and tension force measurement, it boasts reliable performance under loads up to 450kg-safe up to 150% overload. Utilise Offer and Redeem the advantage of manual-grade installation, through or center hole mounting, with a standard 3m cable. Pick Yours-ideal for industrial weighing, material testing, and process control.

Versatile Industrial Applications

The Pancake Load Cell - 450kg excels in Industrial Weighing, Testing Machines, and Material Testing. Its Application Method allows for simple center or through-hole mounting, ensuring secure and accurate force transmission. Type Of Usage spans both compression and tension measurements, enabling seamless integration into areas like process control, weighing stations, and testing setups. Suitable for distributors and industrial users, its robust construction ensures high reliability and consistent results in demanding environments.

Global Export Markets and Certifications

Our Pancake Load Cell - 450kg is available for Delivery across Main Export Markets including India, and supports Express Shipping for urgent needs. While there is no explicit Sample Policy, proposal amounts for quotes can be provided upon enquiry. Though specific certifications are not detailed, the device maintains standard industrial compliance for force measurement, offering peace of mind to manufacturers, suppliers, importers, and traders seeking reliable solutions.

FAQ's of Pancake Load Cell -450kg:

Q: How is the Pancake Load Cell -450kg typically installed?

A: The load cell is mounted using a through hole or center hole, making installation simple and secure for both compression and tension measurements in industrial settings.

Q: What benefits does the hermetically sealed design provide?

A: The hermetically sealed construction ensures protection against dust and moisture, rated at IP65, enhancing the durability and longevity of the load cell in harsh environments.

Q: Where can the Pancake Load Cell -450kg be effectively utilised?

A: This load cell is ideal for industrial weighing, testing machines, material testing, and process control, making it suitable for manufacturers, exporters, and traders in various sectors.

Q: What is the safe and ultimate overload capacity?

A: The load cell safely operates up to 150% of its rated 450kg capacity, with an ultimate overload limit of 200%, ensuring resilience under high-load conditions.

Q: How do I connect and use the device for force measurement?

A: Simply connect the 3 m cable and supply 10 VDC (typical). The analog signal output (2 mV/V) can be read using compatible devices for precise force measurement and monitoring.
