ADI-60510 Aluminum Load Cell 100kg

1000 INR/Piece

Get a Price/Quote

Product Details:

Connectivity Type Wired
IP Rating IP65
Size 130 x 30 x 22 mm (Typical)
Power Source Not Applicable (Non-powered)
Application Electronic Weighing Systems, Automation, Industrial Scales
Usage Industrial Weighing, Platform Scale Integration
Features High precision, Lightweight, Easy installation, Corrosion-resistant
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

ADI-60510 Aluminum Load Cell 100kg Price And Quantity

Price 1000 INR/Piece
Minimum Order Quantity 1 Piece

Rated Output 2.0 0.2 mV/V
Output Resistance 350 5
Temperature Effect on Zero 0.02% of Rated Output/C
Excitation Voltage 5V to 12V DC (Recommended 10V DC)
Cable Length 2 meters (4-core shielded)
Operating Temperature Range -10C to +40C
Temperature Effect on Output 0.02% of Applied Load/C
Zero Balance 1% of Rated Output
Model Number ADI-60510
Safe Overload 120% of Rated Capacity
Creep (30 min) 0.02% of Full Scale
Ultimate Overload 150% of Rated Capacity
Input Resistance 410 15

ADI-60510 Aluminum Load Cell 100kg Product Specifications

Automatic Grade Manual
Features High precision, Lightweight, Easy installation, Corrosion-resistant
Interface Strain Gauge Output (Analog)
Function Weight Measurement/Force Sensing
Accuracy 0.02% of Full Scale
Load 100kg
Capacity Range Up to 100kg
Color Silver/Metallic
Size 130 x 30 x 22 mm (Typical)
Weighing Scale Type Platform Scale, Bench Scale, Electronic Scale
Warranty NO RETURN / REPLACEMENT / GURRENTY OR WARRENTY
Material Aluminum Alloy
Connectivity Type Wired
IP Rating IP65
Product Type ADI-60510 Aluminum Load Cell 100 kg
Usage Industrial Weighing, Platform Scale Integration
Power Supply Not Applicable (Passive Device)
Power Source Not Applicable (Non-powered)
Application Electronic Weighing Systems, Automation, Industrial Scales

Rated Output 2.0 0.2 mV/V
Output Resistance 350 5
Temperature Effect on Zero 0.02% of Rated Output/C
Excitation Voltage 5V to 12V DC (Recommended 10V DC)
Cable Length 2 meters (4-core shielded)
Operating Temperature Range -10C to +40C
Temperature Effect on Output 0.02% of Applied Load/C
Zero Balance 1% of Rated Output
Model Number ADI-60510
Safe Overload 120% of Rated Capacity
Creep (30 min) 0.02% of Full Scale
Ultimate Overload 150% of Rated Capacity
Input Resistance 410 15

ADI-60510 Aluminum Load Cell 100kg Trade Information

FOB Port EX WORKS AHMEDABAD
Supply Ability 100 Piece Per Month
Delivery Time 5 Week
Packaging Details STANDARD CORRUGATED BOX, Shipping cost will depend on location & volume
Main Domestic Market All India

Product Description

Pick yours today and experience the masterful engineering of the ADI-60510 Aluminum Load Cell 100kg, where every feature is highlighted for ineffable precision. Built with unassailable aluminum alloy, this latest strain gauge load cell executes high-accuracy weight measurement for platform and bench scales. Exceptional stability is ensured by a rated output of 2.00.2 mV/V and an IP65 corrosion-resistant finish. Its lightweight, easy installation and superior creep resistance make it ideal for demanding industrial automation environments. Discover reliability-without compromise or warranty.

Versatile Application & Integration

The ADI-60510 Aluminum Load Cell 100kg excels in a diverse range of application areas such as electronic weighing systems, automation setups, and industrial scales. Typically installed on platform or bench scales, its specific usage includes precise weight measurement and force sensing. Application methods involve straightforward mechanical mounting-thanks to its compact dimensions and easy wiring-allowing seamless integration with platform scale bases for accurate and stable readings across industrial weighing operations.

Premium Export Markets & Delivery Solutions

As a highlighted, premium export product, the ADI-60510 Aluminum Load Cell 100kg is consistently delivered to markets across Asia, North America, and Europe. Estimated delivery times and transport services ensure quick turnaround, dependent on order volume and distance. Flexible payment terms include TT and advance options to suit distributors and importers. Our streamlined logistics, partnered with reputed transport services, offer both efficiency and reliability-making global procurement effortless and dependable.

FAQ's of ADI-60510 Aluminum Load Cell 100kg:

Q: How is the ADI-60510 Aluminum Load Cell 100kg typically installed?

A: The load cell is installed onto platform or bench scales using its designated mounting points and is wired through its 2-meter 4-core shielded cable for strain gauge output to a compatible weighing indicator or controller.

Q: What specific industries benefit most from using this load cell?

A: Industries focused on automation, electronic weighing systems, and industrial scales find the unassailable precision and corrosion resistance of this load cell especially beneficial for consistent, high-accuracy weight measurements.

Q: Where can the ADI-60510 Load Cell be applied?

A: It is applied in electronic weighing systems, industrial automation, platform scales, bench scales, and any scenario where accurate force sensing and weight measurement are critical.

Q: What is the main benefit of using this aluminum alloy sensor over traditional designs?

A: Its highlighted features include a lightweight and corrosion-resistant body, masterful accuracy (0.02% of full scale), and easy installation, making it suitable for both new projects and retrofitting existing systems.

Q: What is the process for ordering and delivery, and are there options for international shipping?

A: Ordering involves contacting your distributor, supplier, or exporter, with transport services covering both domestic and international shipping. Estimated delivery timelines depend on location and quantity, with payment terms such as telegraphic transfer and advance accepted.
