CZL-601D 40 KG Load Cell

Product Description

CZL-601 loadcell
cap : 40kg
no warranty / gurrenty / return / replacement in loadcell

Model CZL 601 (Table Top- D ) is strain gauge based LoadCell constructed from Aluminum Alloy for high Accuracy. It is mainly used in check weighing. Suitable for Pan size upto 250mm X 350mm. We are a prominent Exporter, Importer and Supplier of Load Cell Czl 601D. Load Cell (CZL-601D) is made of alloy aluminum. Load Cell (CZL-601D) is hermetically sealed with glue to IP65, surface anodized and anti-corrosion, integral structure and easy installation. Load Cell (CZL-601D) is best suited for electronic table top scale, floor scale and other weighing equipment

High Accuracy and Reliability

The CZL-601D load cell ensures consistent and accurate weight measurements up to 40 kilograms, featuring a rated output of 2.0 0.002 mV/V and meeting the C3 accuracy standard (0.02% FS). Its temperature compensation and low creep characteristics maintain precision, making it ideal for sensitive weighing tasks in both industrial and commercial settings.


Versatile Installation and Applications

Compact and straightforward in design, the CZL-601D is suitable for a broad range of applications including electronic scales, industrial weighing systems, electronic counting scales, and retail weighing equipment. Its 4-wire connectivity and 2-meter standard cable facilitate easy installation, while the durable IP65-rated housing protects against dust and moisture ingress.


Robust Construction and Operational Durability

Engineered to withstand industrial conditions, the load cell supports a safe overload up to 120% and an ultimate overload up to 150% of rated capacity. With an operational temperature range from -10C to +40C and insulation resistance above 2000 M, the CZL-601D maintains dependability even under challenging circumstances.
